Engine & Drivetrain
|
Cooling | Liquid |
| Cylinders Displacement | 567cc | |
| Engine Type | Prostar 4-Stroke DOHC Single Cylinder | |
| Fuel System/Battery | Electronic Fuel Injection / 340 CCA | |
| Horsepower | 44 HP | |
| Transmission/Final Drive | Automatic PVT P/R/N/L/H In-line Shifting | |
| Drive System Type | One Touch On-Demand AWD/2WD | |
| Engine Braking System | Equipped | |
| Active Descent Control | Equipped | |
|
Dimensions
|
Bed Box Dimensions (L x W x H) | N/A |
| Estimated Dry Weight | 848 lbs (385 kg) | |
| Front/Rear Rack Capacity | 90 lb /180 lb (40.8 kg /81.6 kg) | |
| Hitch Tow Rating | 1,350 lb (612 kg) | |
| Hitch Type | Standard 1.25 in (3.2 cm) Receiver | |
| Fuel Capacity | 4.5 gal (17.0 L) | |
| Ground Clearance | 11.5 in (29 cm) | |
| Overall Vehicle Size (L x W x H) | 83 x 48 x 47 in (210.8 x 121.9 x 119.4 cm) | |
| Payload Capacity | 485 lb (220 kg) | |
| Person Capacity | 1 | |
| Seat Height | 33.25 in (84.5 cm) | |
| Wheelbase | 50.5 in (128.3 cm) | |
|
Suspension
|
Front Suspension |
Sealed Arched Dual A-Arm 8.9 in (22.6 cm) Travel
|
| Rear Suspension |
Sealed Dual A-Arm, IRS 9.5 in (24.1 cm) Travel
|
|
|
Tires / Wheels
|
Front Tires | 26 x 8-14; DURO |
| Rear Tires | 26 x 10-14: DURO | |
| Wheels | 14 in. (35.6 cm) Aluminum | |
|
Brakes
|
Front/Rear Brakes |
Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake
|
| Parking Brake |
Park In-Transmission / Lockable Hand Lever
|
|
|
Additional Specifications
|
Electronic Power Steering | Multi Select EPS |
| Cargo System |
Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage, 6 Gal (27.3L) Rear Dry Storage
|
|
| Instrumentation |
All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light
|
|
| Lighting |
LED POD, LED Bumper Lights, Dual LED Brake lights/Taillights
|
|
| Other Standard Features |
Front Trail Bumper, 2,500 lb. Polaris HD Winch, 12 Volt Power Plug, Pre-Wired for Hand & Thumb Warmers, In Pod Battery Charger, Painted Plastics, Front and Rear A-Arm Guards
|
